Industrial Ovens

MTF is praised for catering a conventional range of Industrial Ovens and counted as one of the reliable Industrial ovens manufacturers suppliers and exporters. Our range of oven includes Heating Oven, Tunnel Oven, Tempering Oven, Hot Air Oven, Tray Ovens, Electric Oven, Fuel Fired Oven, Curing Oven, Baking Oven, Drying Oven, Conveyor Oven, Paint Curing Oven, Preheating Oven, Electrode Drying Oven, and Powder Coating Oven. The ovens are manufactured using optimum quality materials advance technology that ensures a perfect match to the international standards.

These ovens are basically used as heating devices, widely used in applications such as baking, drying & curing. Buyers are facilitated with the availability of the Industrial Ovens at market leading prices. The ovens are also available in various specifications to meet the specific requirements of different industrial sectors. The conventional packaging also ensures for delivery of the orders with zero transit loss.

MTF Design & Manufacturing offers the know-how, experience, innovation and creativity to provide custom-made industrial ovens tailored to each customer's unique need.

We LOVE a Challenge! We can make our industrial ovens to :

  • Fit in a tight spot
  • Meet an unusual capacity
  • Accommodate a certain process
  • You Name It!

Our highly qualified technical team can assist with the design, production and installation of a variety of ovens to meet most large heating requirements. Following initial discussion to define precise requirements we can provide advice, full specifications, general arrangement drawings and a comprehensive quotation.

Meta Therm Furnace Pvt. Ltd. are the manufacturer of Industrial Ovens in India. As an Industrial oven manufacturer, we have supplied many Industrial Ovens of Various types such as Batch Oven, Tray oven, Trolley Oven, Conveyor Oven, which operate in temperature ranges from 50ºC to 450ºC using electricity, gas, or oil. Applications include pre-heating, drying, curing, heat-treatment and burn-off to name a few.

MTF make Industrial Oven is of triple wall construction with minimum of metal to metal contact to avoid Heat Bridge in structural design to minimize the conduction of heat emission & reduce energy consumption.

The Outer casing is made from MS coated with epoxy based primers & then with 2 coats of enamel or epoxy paint or powder coated, thus giving rust proof & long lasting performance.

The inner & Baffle Casing can be of MS or SS. The MS sheets are painted with Heat Resisting Aluminum paints of suitable grade. The SS baffles are mirror polished finished for aesthetic looks. For larger size of ovens, we have provided Double Baffle with second being perforated, resulting in high temperature uniformity inside the heating chamber.

The insulation provided are of various density of Rockwool Slab to keep the skin temperature to

minimum & thereby & reduce energy consumption.The impellers & Shaft of Re-circulating fans are statically & dynamically balanced. The Re-circulating fan provides uniform air flow inside the heating chamber. We can design different air flows such as Horizontal air flow, vertical air flow, or Combination of Horizontal & Vertical air flow.

The controls can be ON – OFF type for economical Heating, PI Controller for faster Heating, PID Controller for precise Heating, Profile PID Controller to achieve any time – temperature heating, PLC for automation & SCADA / HMI for user friendly control & management. We provide Thyristors of SCR – Diode type & SCR – SCR type, which reduces the voltage as demanded by the system & gives precise & accurate control of + 1 deg C & also helps in saving energy consumption by reducing voltage & thereby power mainly during soaking period.

Our products are widely used in various Industries & repeated orders from companies such as M/s. TATA Steel Ltd, Crompton Greaves Ltd., Bharat Bhijllee Ltd. & even repeated export orders certifies about our Quality & Services & has helped us become pioneers among manufacturers and suppliers of Industrial Ovens in India.

Our range of Customised Industrial Ovens includes Heating Oven, Tunnel Oven, Tempering  Oven, Hot Air Oven, Tray Ovens, Electric Oven, Fuel Fired Oven, Curing Oven, Baking Oven,  Drying Oven, Conveyor Oven, Paint Curing Oven, Preheating Oven, Electrode Drying Oven,  and Powder Coating Oven. The ovens are manufactured using optimum quality materials  advance technology that ensures a perfect match to the international standards.Each oven is completely assembled, wired and factory tested prior to shipment to ensure the highest quality.
